◆ Description:
Miray GE-BX40-SM4931 Transceivers are a high performance, cost effective module which have a single LC optics interface. They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472. The receiver section uses a PIN receiver and the transmitter uses a 1490 nm DFB laser, up to 21dB link budge ensure this module 1000Base-EX Ethernet 40km application.
Specifications
| Part Number: | GE-BX40-SM4931 | Vendor Name: | Miray |
| Form Factor | SFP | Max Data Rate | 1.25Gbps |
| Wavelength | TX1490nm/RX 1310nm | Max Cable Distance | 40km |
| Media | SMF | Connector | Simplex LC |
| Transmitter Type | DFB BiDi | Receiver Type | PIN |
| TX Power | -2~+3dBm | Receiver Sensitivity | <-23dBm |
| Electrical Modulation | 1.25Gb/s NRZ | Optical Modulation | 1.25Gb/s NRZ |
| Power Consumption | ≤1.0W | CBit Error Ratio(BER) | 10-12 |
| Temperature Range | 0 to 70℃(32 to 158°F) | Operating Relative Humidity | 5%～85% |
| Protocols | Gigabit Ethernet,Gigabit Fibre Channel,MSA Compliant |
Main application environments |
Gigabit Ethernet Switches and Routers,Fiber Channel Switch Infrastructure,Other Optical Links |
