Specifications
| Product Series | Fiber Optical Transceiver | Optcore Part Number | GE-SX-MM1310 |
| Form Factor | SFP | Data Rate | 1.25 Gb/s |
| Wavelength | 1310 nm | Cable Type | MMF |
| Max Distance | 2 km over OM2 | Optical Components | FP/PIN |
| Transmitter Power | -9 ~ -3 dBm | Extinction ratio | > 9 dB |
| Receiver Sensitivity | < -18 dBm | Receiver Overload | > -3 dBm |
| Connector | LC Duplex | Digital Diagnostic Monitoring | Yes or No |
| Environment | Operating: 0°C to 70°C Storage: -40°C to 85°C |
Weight | 0.025 kg |
| Application | 1G Fiber Channel, Switch to Switch Interface Gigabit Ethernet, Switched Backplane Applications Broadband aggregation and wireless infrastructure Router/Server Interface Other Optical networking |
Compliance | IEC/EN 61000-4-2,IEC-60825 FDA 21CFR 1040.10 and 1040.11 RoHS |
