This 24 ports gigabit Switch provides a high-performance switch architecture that is capable of providing the non-blocking switch fabric and wire-speed throughput as high as 64Gbps, which greatly simplifies the tasks of upgrading the LAN for catering to increasing bandwidth demands. Besides, the Flow Control function of the switch enables routers and servers to directly connect to the Switch for fast and reliable data transfer.
All the RJ45 copper interfaces of the MR-224G-2SFP support 10/100/1000Mbps auto-negotiation for optimal speed detection through RJ45 Category 6, 5 or 5e cables. It also supports standard for auto-MDI/MDI-X that can detect the type of connection to any Ethernet device without requiring special straight or crossover cables. With 2 SFP module slot available, the SFP uplink port is ideal for connecting the switch to the network’s backbone, providing more than enough bandwidth and stability for ultra high speed data transferring, Beside the SFP can transmitte the date with Max 100Km distance with more economic solution.
|
Model No. |
MR-1001S20 |
|
Standards |
IEEE802.3z/AB, 10/100/1000Base-T and 1000Base-SX/LX |
|
Number of Ports |
4 Port 10/100/1000Base-Tx and 1 Port 1000Base-Fx |
|
Mode Type |
Single Fiber SM 20km Tx: 1310nm/Rx:1550nm |
|
Transmission Rate |
10 Mbps: 14880 pps, 100Mbps: 148800 pps, 1000Mbps:1488000 pps |
|
Switching Mode |
Store-and-Forward |
|
Flow Control Mode |
IEEE 802.3x full-duplex flow control and back pressure flow control |
|
MAC address |
1K |
|
Frame buffer memory |
512Kb RAM |
|
Bandwidth |
12G, can be transmitted to achieve non-blocking wire-speed |
|
LED Status Indicator |
LED status of Link, activity, Full/half duplex, speed, and power on diagnostic function |
|
Cable Support |
UTP cable: 3, 4 or Cat. 5,cat6 (the max distance up to 100m) |
|
Power Supply |
AC100 ~240V, 50~60Hz; DC5V 2A |
|
Size |
95*70*25mm |
|
Net Weight |
0.35kg |
|
Operating Temperature |
0 °C to +70 °C |
|
Storage Temperature |
-20 °C to +80 °C |
|
Storage Humidity |
5% to 90% RH |
