Standard 10G SFP+ LRM Optical Transceiver | 1310nm | Duplex LC | 220M | DDM
Product Overview
The Miray SFP-10G-LRM is a compact 10Gb/s optical transceiver designed for legacy multimode fiber upgrades. Utilizing a 1310nm FP transmitter and PIN receiver, it is fully compliant with the IEEE 802.3aq 10GBASE-LRM standard, providing a cost-effective solution for transmitting 10G data up to 220m over existing multimode fiber (MMF).
Download DatasheetKey Features
- Supports 9.95 to 11.3 Gb/s bit rates
- Hot-pluggable SFP+ footprint
- Duplex LC connector
- 1310nm FP transmitter, PIN photo-detector
- MMF links up to 220m
- Compliant with IEEE 802.3aq 10GBASE-LRM
- Power supply: +3.3V, power consumption < 1W
- Temperature range: 0°C to 70°C
Typical Applications
- 10GBASE-LRM Ethernet
- Legacy FDDI multimode links
Technical Specifications
| Parameter | Value |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 9.95 ~ 11.3 Gb/s |
| Wavelength | 1310nm |
| Distance | Up to 220m |
| Connector | Duplex LC |
| Fiber Type | MMF |
| Transmitter | FP |
| Receiver | PIN |
| DDM | Yes |
Compatibility
100% compatible with Cisco and other major brand switches and routers. Each module is fully tested before shipment. Custom coding available on request.
