Standard 10G SFP+ LRL Optical Transceiver | 1310nm | Duplex LC | 2KM | DDM
Product Overview
The Miray SFP-10G-LR02 is a compact 10Gb/s optical transceiver designed for short-reach single-mode applications. Utilizing a high-performance 1310nm FP transmitter and high-sensitivity PIN receiver, it provides a cost-effective solution for 10G Ethernet links up to 2km over single-mode fiber (SMF).
Download DatasheetKey Features
- Supports 9.95 to 11.3 Gb/s bit rates
- Hot-pluggable SFP+ footprint
- Duplex LC connector
- 1310nm FP transmitter, PIN photo-detector
- SMF links up to 2km
- 2-wire interface compliant with SFF-8472 DDM
- Power supply: +3.3V, power consumption < 1W
- Temperature range: 0°C to 70°C
Typical Applications
- 10GBASE-LR/LW Ethernet
- SONET OC-192/SDH
- 10G Fibre Channel
Technical Specifications
| Parameter | Value |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 9.95 ~ 11.3 Gb/s |
| Wavelength | 1310nm |
| Distance | Up to 2km |
| Connector | Duplex LC |
| Fiber Type | SMF |
| Transmitter | FP |
| Receiver | PIN |
| DDM | Yes |
Compatibility
100% compatible with Cisco and other major brand switches and routers. Each module is fully tested before shipment. Custom coding available on request.
