Standard 10G Bidi SFP+ Transceiver | Tx1270/Rx1330nm | Simplex LC | 20KM | DDM
Product Overview
The Miray SFP-10G-BX20-SM1270 is a Bi-directional 10Gb/s (SFP+) transceiver compliant with SFP+ MSA. Operating at Tx 1270nm / Rx 1330nm over a single strand of single-mode fiber (SMF), it provides a cost-effective solution for 10G Ethernet applications up to 20 kilometers.
Download DatasheetKey Features
- Supports 9.95Gb/s to 11.3Gb/s bit rates
- Hot-pluggable SFP+ footprint
- Single LC for Bi-directional Transmission
- Maximum link length of 20km
- Built-in 1270/1330 WDM Filter
- Uncooled 1270nm or 1330nm CWDM DFB Laser
- Built-in digital diagnostic functions (DDM)
- Power dissipation < 1.5W
- Operating temperature: 0°C to 70°C
Typical Applications
- 10GBASE-LR/LW Ethernet
- SONET OC-192/SDH
- 10G Fibre Channel
Technical Specifications
| Parameter | Value |
|---|---|
| Form Factor | SFP+ |
| Data Rate | 9.95 ~ 11.3 Gb/s |
| Wavelength | Tx 1270nm / Rx 1330nm |
| Distance | 20km |
| Connector | Simplex LC |
| Fiber Type | SMF |
| DDM | Yes |
Compatibility
100% compatible with Cisco and other major brand switches and routers. Each module is fully tested before shipment.
